Designed with a sleek, open-frame structure, it eliminates back and side panels to provide unobstructed access for forklifts and manual handling—perfect for small and medium-sized warehouses, workshops, and retail stores. Featuring adjustable cantilever arms, corrosion-resistant surface treatments, and a modular design, this rack balances flexibility, economy, and functionality. Whether storing aluminium profiles, plastic pipes, or light steel plates, the Light Duty Cantilever Rack maximizes space utilization while keeping materials organized and easily accessible.
The open design of the Light Duty Cantilever Rack eliminates wasted space from traditional enclosed racks. It stores long materials (up to 1200mm arm length) without overlapping, maximizing floor and vertical space efficiency—critical for facilities with limited storage height (under 3.5m).
Cantilever arms adjust in 100mm increments, adapting to varying material heights and sizes. Whether storing short pipes or long profiles, the rack’s flexibility eliminates the need for multiple fixed racks, simplifying inventory management.
Compared to heavy-duty cantilever racks, the Light Duty Cantilever Rack uses lighter materials, reducing costs by 30%–50%. It delivers reliable performance for lightweight loads (up to 400kg per arm) without the premium price tag, ideal for small-scale operations.
Offering two surface options—powder coating (RAL2004) for indoor use and hot-dip galvanizing for outdoor use—the rack resists rust and wear. This ensures durability in diverse environments, from dry workshops to humid outdoor storage areas.
Pre-welded columns and bases simplify assembly—no welding or specialized tools are required. The modular design allows teams to set up the rack in hours, minimizing downtime and getting your storage system operational quickly.
Easily add extra cantilever layers or extend arm lengths as your storage needs grow. The rack’s modular structure supports single-sided or double-sided configurations, adapting to changing warehouse layouts and inventory volumes.
Parameter | Specification |
Rack Type | Light Duty Cantilever Rack |
Arm Length | 500~1200mm |
Column Height | 1500~3000mm (suitable for low-ceiling environments <3.5m) |
Load Per Arm | 50~200kg (max 400kg per arm) |
Total Load Capacity | ≤3000kg per bay |
Column & Base Profile | C200x60, HS100*50 (Hollow Section), C80x60 |
Material | Hot-dip galvanized coil (pre-welded base) |
Surface Treatment | Powder coated (RAL2004) – indoor; Hot-Dip Galvanized – outdoor |
Arm Components | Welded bracket, arm nose, clevis pin & R-clip, optional arm stopper |
Compliance Standards | ISO9001, CE, AS4084, FEM Certification |
| Light-duty cantilever racking is a type of storage equipment specially designed for long, ring-shaped or irregular materials. It is suitable for small and medium-sized warehouses, workshops, retail stores and other scenarios. It features a lightweight structure, strong flexibility and high space utilization. |
Cantilever Racking Type | Arm Length(mm) | Column Height(mm) | Load Per Arm(Kg) | Total Load Capacity(Kg) |
Light Duty | 500~1200 | 1500~3000 | less than 400kg | under 3000kg |
Stores lightweight long materials such as aluminium profiles, plastic pipes, and PVC tubes. The rack’s compact design fits in tight spaces, making it ideal for urban warehouses or facilities with limited square footage.
Organizes light steel plates, small metal profiles, and irregular workpieces (e.g., ring-shaped components). The open design allows easy access with hand trucks or small forklifts, reducing material handling time and improving workflow.
Displays or stores long retail items such as furniture parts, packaging tubes, or gardening tools. The clean, modular design integrates with retail environments, keeping products organized and accessible to customers.
Stores lightweight construction materials (e.g., PVC pipes, aluminium framing) in outdoor or indoor yards. The hot-dip galvanized option withstands weather elements, ensuring materials remain in good condition.
The Light Duty Cantilever Rack excels with long, lightweight, and irregular materials: aluminium profiles, plastic pipes, light steel sections, plates, ring-shaped items, and small-diameter tubing. It is not recommended for heavy loads exceeding 3000kg per bay.
Yes. Choose the hot-dip galvanized surface treatment for outdoor use—it provides superior corrosion resistance against rain, humidity, and temperature fluctuations, protecting your materials and extending the rack’s lifespan.
Arms adjust using clevis pins and R-clips, with 100mm pitch intervals. Simply remove the pins, reposition the arm to your desired height, and reinsert the pins—no tools or technical expertise required.
No. The rack comes with detailed installation drawings, and pre-welded components make assembly straightforward. Most teams can install it with ordinary tools in a few hours. We also offer on-site technician support if needed.
 |  |
